Wired Sheep Farm Galvanized Chain Link Fence Roll Breeding Sheep Cattle Swinery Net Orchard

Product Categories
AN PING XI RUN METAL MESH CO.,LTD
Contact Now

Wired Sheep Farm Galvanized Chain Link Fence Roll Breeding Sheep Cattle Swinery Net Orchard

  • 1
  • 2

Brand Name : XR

Certification : SGS ISO

Place of Origin : CHINA

MOQ : 1 Roll

Price : Negotiation

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 10000 m² Per Week

Delivery Time : 7 Days After Payment

Packaging Details : Plastic Woven Bag

Product Name : Galvanized Wire Mesh Chain Link Fence Breeding Sheep Cattle Swinery Net Orchard Fence

Wire Dia : 9 Ga Or 11.5 Ga

Mesh Shape : Diamond

Material : Galvanized

Roll Size : Could Be Customized

Color : Silver

Including : Chain Link Hardware

Usage : Sheep Farm/ Donkey Farm

Contact Now

Wired Fence For Sheep Farm Galvanized Wire Mesh Chain Link Fence Breeding Sheep Cattle Swinery Net Orchard Fence

Chain Link Fence Description

Chain link gates are most popular with sheep farmers as lambs have a tendency to get through traditional barred gates

Chain Link Fence Paramaters

Product Type Chain-Link Fence Section
Style Chainlink
Material Steel
Color/Finish Galvanized Steel
Overall Height; 48 inch
Overall Length 100 inch
Coating Material Galvanized
Thickness 2-3/8
Including Tension Wire, Top Rail, Post Kits, Posts, Tension Bars, Concrete, Hardware, Fabric


Chain Link Fence Data Techinique

Chain link fence System:
Chain-Link Fabric
Type
Specification
Gauge
Mesh
Heights
Selvage		 Galvanized before Weaving
Low carbon steel wire
9 or 11
2"
3', 42", 4', 5', 6', 7', 8', 10' and 12' or as your request
Knuckled and Knuckled, Barb and Knuckled 6', or Barb and Barb
Framework
Top Rail
3' to 5' High

6' to 12' High		 32mm O.D.

42mm O.D.
Line Posts
3' to 5' High

6' to 12' High		 48mm O.D.

60mm O.D.
Terminal Posts
3' to 12' High

For Heavy Gates		 60mm O.D.

100mm O.D.
Gate
Fabric
Frame		 Same Mesh and Gauge as Chain Link Selected
Same as Top Rail Selected
Fittings
Steel Fittings
Tie Wires		 Hot Dip Galvanized Or PVC coated available
galvanized
Caps, Eye Tops,
Rail Ends		 Malleable, Cast Iron Steel, Pressed
Material Composition
Colors		 Polyethylene Thermoplastic

Green, Black, Brown, Gray, Redwood, Blue, Desert Sand

Chain Link Fence Features

  1. Two heavy duty one piece adjustable hinges hot dip galvanised.
  2. Hot dip galvanised frame
  3. 75mm diamond mesh and 25mm pipe frame
  4. Two weld on hinge sockets
  5. Durable and long lasting

Chain Link Fence Application

  1. Pig cage;
  2. Chicken coop;
  3. Sheep farm;
  4. Turkey cage;
  5. Donkey farm.

Chain link mesh mechanically tensioned in frame before tying with 2mm soft tie wire,

and then double knotted.

Farm gate Length Height
XRQ1 3.66 (metres) / 12' (feet) 1.50 (metres) / 4' 9" (feet)
XRQ2 3.05 (metres) / 10' (feet) 1.88 (metres) / 6' 2" (feet)
XRQ3 3.66 (metres) / 12' (feet) 1.88 (metres) / 6' 2" (feet)
XRQ4 4.27 (metres) / 14' (feet) 1.88 (metres) / 6' 2" (feet)
